What Does a Pad Mounted Transformer Do?

A pad mounted transformer is a type of electricity distribution transformer that is installed on a concrete pad at ground level to convert electrical power to voltages and currents that are safe and usable for homes, businesses, and utility companies. Being a key component of any electrical power distribution network, its significance cannot be overstated.

II. The Purpose of a Pad Mounted Transformer

A. Core Functions

At the heart of its functionality, a pad mounted transformer performs two main tasks:

  1. Step Down Voltage: It receives high-voltage electrical energy from a power line via an overhead or underground feeder circuit and “steps it down” to a lower voltage that is safe and usable for end users.
  2. Distribute Power: Once the voltage is stepped down, the transformer distributes this electrical power to residential, commercial, or industrial users.
What Does a Pad Mounted Transformer Do

Liquid-Filled Radial Feed Pad Mounted Transformer

Rated Power:75~2500 kva No-load Loss:180~2680W On-load Loss:1250~27786W

Liquid-Filled Loop Feed Pad Mounted Transformer

Primary Voltage Ratings: 34.5-19.92/13.8-7.957/13.2-7.62/12.47-7.2 or others

Small Substation Transformer

Primary Voltage Ratings: 2.4kV/4.16kV/4.8kV/6.9kV/7.2kV/ 12kV/12.47kV/13.2kV/13.8kV/ 23kV/34.5kV/44kV TYPE: Oil immersed BIL: 95

Single Phase Pad mounted transformer

Rated Power:15~167 kva No-load Loss:50~350W On-load Loss:195~1410W

Table of Contents

B. Serving Different Scenarios

Depending on their design and specifications, pad mounted transformers can serve a variety of scenarios, including:

  1. Residential Areas: For homes, a pad mounted transformer can provide the safe and appropriate voltage for household appliances.
  2. Businesses: In commercial setups, these transformers distribute the right voltage for running office equipment, HVAC systems, lighting, and more.
  3. Utility Companies: For utility companies, they play a vital role in electricity transformer box applications, effectively managing power distribution across various consumer types and loads.

Here is a pie chart representing the different applications of pad mounted transformers:

Applications of Pad Mounted Transformers


III. Different Types of Pad Mounted Transformers

Pad mounted transformers come in various types, each tailored to specific needs and applications.


A. Single-Phase Pad Mounted Transformers


Single-phase pad mounted transformers are often utilized in residential areas where the electrical load is relatively low. They’re perfect for powering household appliances and small offices. Single-phase transformers by Daelim, such as our single-phase pad mounted distribution transformer, are designed to provide a safe and reliable power supply.


B. Three-Phase Pad Mounted Transformers


Three-phase pad mounted transformers are generally used in commercial and industrial applications, where the electrical load is high. They’re necessary for powering industrial equipment, large commercial buildings, and machinery. Daelim’s liquid-filled loop-feed pad-mounted transformer and liquid-filled radial-feed pad-mounted transformer are excellent examples of three-phase transformers designed for efficiency and durability.


C. Pad Mounted Transformers with Different Power Ratings


Depending on the application, you may require a pad mounted transformer with a specific power rating. Daelim offers transformers with various power ratings, including:


Here is a pie chart representing the different types of pad mounted transformers:


Types of Pad Mounted Transformers


IV. Key Brands and Products: Spotlight on Daelim


A. Overview of Daelim’s Products


Daelim’s range of products extends beyond transformers to include substations, power storage solutions, and charging stations. Each product is engineered for durability, efficiency, and superior performance. To explore the complete range, visit our Daelim collections page.



Here are some of the top pad-mounted transformer products offered by Daelim:


  1. YB Pre-Compact Substation: A versatile and compact solution ideal for space-restricted applications.
  2. Single-Phase Overhead Conventional Transformer: Perfect for overhead power distribution in suburban areas, small industries, and farms.

V. The Role of Pad Mounted Transformers in Specific Contexts


A. Power Storage


In the world of renewable energy and power storage, pad mounted transformers play a crucial role. They ensure that power stored from renewable sources can be distributed at usable voltages.


B. Public Electric Charging Stations


As the world moves toward electric vehicles (EVs), the demand for public electric charging stations is on the rise. These stations require reliable and efficient power distribution systems. Pad mounted transformers ensure that these stations can safely and efficiently deliver power to electric vehicles.


C. Bitcoin Mining


In the realm of digital currencies, Bitcoin mining is a power-intensive operation. For these mining facilities, pad mounted transformers can ensure that power is efficiently distributed to maintain continuous operations.


VI. Pricing and Purchasing a Pad Mounted Transformer


A. Factors Affecting the Price


The cost of a pad mounted transformer can depend on several factors:

  1. Power Rating: Transformers with higher kVA ratings usually come at a higher price.
  2. Brand: The manufacturer’s reputation and the quality of their products can influence the price.
  3. Type: Whether it’s a single-phase or three-phase transformer can affect the price.
  4. Additional Features: Transformers with additional features, such as advanced cooling systems or smart monitoring capabilities, may be priced higher.

Here is a pie chart representing the different factors that affect the price of a pad mounted transformer:


Factors Affecting the Price of a Pad Mounted Transformer

B. Daelim’s Pad Mounted Transformer Price List

Daelim provides a range of high-quality transformers at competitive prices. Our pad mounted transformer price list offers an overview of our product range and their prices.


VII. Maintenance and Technical Parameters of a Pad Mounted Transformer


A. Overview of the Maintenance Required


Regular maintenance is crucial to ensure the longevity and efficiency of a pad mounted transformer.


B. Description of Key Technical Parameters


Understanding the key technical parameters of a pad mounted transformer can help you choose the right product for your needs.


VIII. Conclusion


The importance and versatility of pad mounted transformers cannot be overstated. Daelim is here to ensure you have the best equipment for your needs. Visit us today and let’s power the future together!
